Wildtan M-5600 Mid-Drive E-Bike

1000W Hunting Electric Fat Bike, Durable Rear Rack as Gift
(1 Review)
Price:
USD
$3599.00
$5599.00

    Please select the information you wantX
  • Color:
    Classic Black
    Camo
    Volcano Ash
Quantity:
-
+
I agree to the AddMotor terms of purchase
48V*1000W
Mid-Drive Motor
Up to 60+
Miles per Charge(Estimate)
48V*17.5Ah
Panasonic Lithium-ion Battery
350lbs
Payload Capacity

Fun Features Fun Features
Fun Features

Measurements Measurements
Measurements

Video Review Video Review
Video Review

Conquer The Terrains

Wildtan mid-drive electric bike is built to be taken up hills, down log roads, and through wooded areas where regular city electric bikes would not be equipped to handle. A 1000W Bafang Mid-drive motor hidden in the frame, coupled with a long-lasting 17.5Ah Panasonic battery, allows you to freely shuttle through various terrains and enjoy the fun of exploration.



BBSHD Bafang Mid-Drive Motor

Rated power at 1000w, the mid-drive motor provides strong power constantly enough in continuous steepest hills. Sit encased in the frame between the pedals and offer a more balanced, the mid-drive motor has a variable speed cutoff sensor that makes the shift smoother. The minimum ratio 1.125:1 helps the bike own a 160N·M super high torque, any tough terrains never be a big deal.

6061 Aluminum Alloy Frame

Designed with a high-quality 6061 aluminum alloy frame, the WILDTAN mid-drive electric bike is super solid and durable to carry a lot including you and your gears. With a professional flat welding process, the extra bold frame shows up a simple but strong, as well as a unique look.

17.5Ah Panasonic battery

Ultra-large capacity 17.5Ah Panasonic battery allows this mid-drive electric bike to go deep into the wood, and you won’t worry about running out of juice while in a 65 miles long-distance adventure. After a whole day hunting or fishing far away, just using the throttle home with your spoils in ease.

5 Inch LCD Smart Color Display

The mid-drive electric bike uses a smart color display the has a Bluetooth connection & Google map direction functionality. Full-Color LCD Display for easier viewing, clearly legible and intuitive to use.

Derailleur

Unlike other Addmotor bikes, the WILDTAN mid-drive electric bike features SHIMANO ALIVIO 9 Speed that provides responsive rear shifting for bike drivetrains. Technology keeps the derailleur safe from trail obstacles.

Air Fork

·  Air Spring Inverted Fork with 120 mm of travel
·  Rebound / Air Pressure Adjustable
·  Manual Lock-out Adjustments
·  Best used for cross country, trail and all-mountain riding

Right Shift

·  SHIMANO ALIVIO Right Shift Lever with Shifting Sensor
·  Suited to quick shifting
·  Able to downshift three gears in one stroke

Disc Brake

·  Tektro Hydraulic Disc Brake HD-E500 With Motor Cutoff Sensor
·  Easier, requires retinal tension braking
·  More suitable for braking in any weather conditions

Technical specs
+Electronics
Battery
48V*17.5Ah (840Wh) With Lithium Panasonic 35GA Cells, rated for 800 charge cycles
Motor
1000W Bafang BBSHD Mid Drive Motor With 160 Nm of torque
Display
Addmotor 5 Inch LCD Smart Color Display with Bluetooth
Throttle
Right Hand Half Twist Throttle
Controller
Integrated Bafang 30A Controller
Lights
Front: Electric headlight TRENDO by Spanninga
Rear: Battery taillight by Spanninga
Integrated Wiring
Water Resistant Connectors And Wiring Harness
Charger
48V, 2.5 Amp smart charger
Pedal Assist
Intelligent 5 level pedal assist With an integrated speed sensor
+Components
Frame
6061 Aluminum Alloy Frame
Front Fork
Air Inverted Fork with 120 mm of travel, Rebound / Air Pressure Adjustable / Manual Lock-out Adjustments
Brakes
Tektro Hydraulic Disc Brake HD-E500 With Motor Cutoff Sensor
Brake Rotors
Tektro 180 mm front and rear
Chain
KMC X9 Rust Resistant Chain
Tires
Kenda Juggernaut Pro 26" x 4.5" Puncture-resistant Fat Tires
Derailleur
SHIMANO ALIVIO 9-speed
Handlebar
Promax Aluminum, 700mm wide, 5° Angle Sweep Back
Pedal
Wellgo aluminum with reflectors, standard 9/16" x 20 TPI threading
Saddle
Exclusive Addmotor Well Padded Saddle
Seat Post
Promax Aluminum 320 mm x 28.6 mm
Seatpost Clamp
Promax Quick release
Stem
Promax Aluminum 100mm + Adjustable Angle (±60°)
Rims
26" Aluminum Double Wall, 36H, With Front Thru-axle Hub
Grips
Durable Imitation leather ergonomic grips
Spokes
12-gauge stainless steel
Freewheel
Exclusive Addmotor Stainless Steel 9-speed Freewheel, 11-32T
Kickstand
Side-mounted, adjustable lean angle
Crankset
36T Chainwheel, 170mm Bafang Forged Alloy
Shifter
SHIMANO ALIVIO Right Shift Lever with Shifting Sensor
Measurement
The powerful mid-drive electric bike strong enough to carry a rider whose height range of 5'10''-6'5'' and weigh 350 lbs.
Total Length
78.5''
Wheelbase
49.5''
Mini/Maxi Seat Height
34''/42.5''
Seat Tube
19''
Stand Over Height
34''
Handlebar Height
44''
Reach
16''
Handlebar Width
28''
